Rotorbake T5 15T Classic

Location:United States

Description

The Rotorbake T5 15T Classic is a high-performance gas oven designed for industrial baking with precision and reliability. With the capability to accommodate up to 15 trays, this oven offers versatility in tray sizes ranging from 40x60cm to 60x65cm, providing a baking surface of up to 5.85 square meters. It operates with a maximum temperature of 270°C, making it suitable for a variety of baking applications. The oven's dimensions are 1150 mm in length, 1730 mm in depth, and 2320 mm in height, optimizing space without compromising on capacity. With a weight of 715 kg, it combines robust construction with advanced baking technology. The unit requires a power supply of 400 V with options for different phases, ensuring compatibility with various electrical infrastructures. Power efficiency is notable, with an energy output of 34.8 kW and a calorific value of 30,000 Kcal/h. The Rotorbake T5 15T is engineered to deliver consistent results, thanks to a reasonable tray distance of 93 mm, allowing even heat distribution. This oven is ideally suited for bakeries seeking dependable and high-capacity baking solutions.

Specifications

ManufacturerRotorbake
ModelT5 15T
Year2026
ConditionNew
Stock Number1012030
TypeGas
Code825818870
Trays15T 40x60cm (3.6m²) | 40x80cm (4.8m²) | 46x66cm (4.55 m²) | 50x70cm (5.25 m²) | 60x65cm (5.85 m²)
Outside dimension1150 L x 1730 P x 2320 H mm
Tray distance93 mm
Power34.8 kW - 30.000 Kcal/h - Ele. 1,6 kW
Weight715 Kg
Max temperature270° C
Power supply400 V ~ 3PH + N + PE 230 V ~ 3PH + PE 230 V ~ 1PH + N + PE 50-60 Hz
